Bastl Instruments Neo Trinity

Bastl Instruments’ Neo Trinity is a powerful six-channel modulation hub designed to offer deep control without sacrificing playability. Whether you're crafting subtle movement or complex algorithmic modulations, Neo Trinity brings serious modulation potential to any Eurorack system.

Each of its six channels (A–F) can function independently as an LFO, envelope, or CV recorder, with parameters that can be recorded, looped, and even manipulated using CV. The LFO mode features multiple waveforms, sync options, and smoothing, while envelope mode provides various trigger types and timing shapes. CV mode records your knob movements and transforms them into quantized or free-form voltage sequences — complete with automation, step lengths, and triggering options.

Where Neo Trinity really shines is its interactive control options. The META input can simultaneously modulate all (or just selected) channels. Channels E and F also have their own CV inputs with flexible assignable behaviors — from rate modulation and VCA control to sample & hold triggering. The result is a playful, dynamic system where modulation can modulate modulation.

Neo Trinity also includes features like an algorithmic trigger fill generator, mutes for each channel, automation memory across six banks, and USB firmware updates. With its internal or external clocking, and the ability to operate as a clock divider or generator, it becomes the rhythmic heart of your patch.

• Six fully independent modulation channels (A–F)

• LFO, envelope, and CV recorder modes per channel

• LFO waveforms: saw, ramp, triangle, pulse, random, with smoothing

• Envelopes: decay, attack, variable shapes, pulse, slew mode

• CV mode with quantizer (8 scales), automation and smoothing

• Record automation from 2–64 steps

• Algorithmic trigger fill generator (6 types)

• Clock sync, division, and reset per channel

• META input for global CV control (assignable to selected channels)

• Separate CV inputs for channels E and F

• Adjustable input functions: rate modulation, VCA, sample & hold, slew trigger

• Activity LEDs per channel

• Mute and memory functions, 6 user banks

• USB firmware updates
